Fresh Water Pump
Pump for Urban Water Supply, Shower Pump, Long Distance Water Supply Pump
Parameters of 4" Fresh Water Pump (WSP100L/E Series)
| Model | WSP100L/E |
| Water pump type | fresh water pump |
| Suction/discharge port diameter (mm) | 100 (4 inches) |
| Max capacity (m3/h) | 96 |
| Max head (m) | 27 |
| Self-priming time (s/4m) | 180 |
| Max suction head (Mpa) | 8 |
| Noise (7m) dB (A) | 79 |
| Rated speed (r/min) | 3600 |
| Power (KW) (HP) | 7.2(10) |
| Starting way | manually/electrically |
| Net weight (Kg) | 69 |
| Engine model | WS188FB |
| Dimension: L ×W ×H (mm) | 650 ×480 ×600 |
