Outboard Diesel Engine, WSFD13
Outboard Marine Engine, Portable Outboard Motor, Diesel Engine Set, Portable Diesel Engine
| Model | WSFD13 | ||
| Engine model | diesel engine, 192 series | ||
| Engine type | single-cylinder, vertical type, 4-stroke, air/water-cooled, direct injection | ||
| Cylinder quantity-cylinder diameter x stroke (mm) | 1-92×75 | ||
| Displacement of piston (ml) | 498 | ||
| Rated speed of output shaft (rpm) | 3000 | 3600 | |
| Rated output power (kw/ps) | 8.5(11.6) | 9.3(12.7) | |
| Rotation direction of output shaft | anticlockwise | ||
| Valve Clearance (mm) | 0.1-0.15 (cold) | ||
| Starting way | manually/electrically | ||
| Fuel | injection pressure Kgf/cm2 (Mpa) | 220-230 (21.6-22.6) | |
| fuel supply advance angle | 20℃±1℃ | ||
| fuel volume (L) | 5.5 | ||
| fuel type | 0# (summer)-10# (winter) | ||
| Engine lubrication | lubrication style | force-feed and splashing system | |
| lubrication oil | SAE10W-30, above level CC | ||
| lubrication oil volume (L) | 1.65 | ||
| Engine size (L x W x H) (mm) | 418×465×495 | ||
| Engine net weight (Kg) | ≤48 | ||
| Machine Net Weight (Kg) | ≤84 | ||
| Speed of impeller (r/min) | ＞1400 | ||
| Diameter of impeller (mm) | ￠340 | ||
| Lubrication for gearbox | lubricating way | force-feed and splashing system | |
| type of lubrication oil | medium load industrial gear oil HL-20 | ||
| lubrication oil volume (L) | 3 | ||
| Applicable ranges | 7-13m ships, with a maximum load of 4 tons | ||
